16GG Fully Jacquard Flat Knitting Machine Double System 52inch for High Production

Name: 16GG Fully Jacquard Flat Knitting Machine Double System 52inch for High Production
Brand: OPEK
Price: 7 USD

Quality 16GG Fully Jacquard Flat Knitting Machine Double System 52inch for High Production for sale

Applicable Industries : Garment Shops, Manufacturing Plant, Farms, Retail, Advertising Company

Condition : New

Product Type : Hat, Scarf, SWEATER

Type : jacquard

Production Capacity : 1.6m/S

Place of Origin : Anhui, China

Brand Name : OPEK

Power : 1.5 W

Knitting Style : flat

Knitting Method : Double

Computerized : Yes

Weight : 650 KG

Dimension(L*W*H) : 2500*850*1600mm

Warranty : 1 Year

Key Selling Points : Low Maintenance Cost

Gauge : 1.5 GG, 3 GG, 12 GG, 14 GG, 2 GG, 16 GG, 9 GG, 5 GG, 10GG, 18GG, 16GG, 8GG, 3-5-7 multi-gauge, 2.5gg,3gg, ,5gg ,7gg ,8gg, 9gg, 10gg, 12gg, 14gg

Knitting width : 52 inch

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Marketing Type : New Product 2020

Warranty of core components : 2 years

Core Components : Motor, Gearbox

Product Name : Chinese sweater computerized flat knitting machine

After-sales Service Provided : Engineers available to service machinery overseas

Knitting system : Single carriage with double system

Keywords : computerized flat knitting machine

Knittind width : 52 inch((36-100 inch all available ))

Machine Type : Fully Jacquard Flat Knitting Machine

Function : Knititing Shoes Upper/sweater/hat

Speed : Higher Speed

Price : $7,000.00/sets 1-9 sets

Contact Now

Product descript

16GG Fully Jacquard Flat Knitting Machine Double System 52inch for High Production

52 inch Economy Double system computerized flat knitting machine

This system is automatic computerized flat knitting machine
It adopts digital technology to realize the knitting functions transfer tuck,eyelet stitch,jacquard,apparent shape, hidden shape and other regular pattern knitting functions.

It can knit basic stitch like plain stitch,rib fabric,links and interlock stitch,etc.
Irregular multi-color jacquard,twisted flower weft organization,cord weave,racked stitch,cable,intarsia,etc.
It is suitable to use synthetic,wool,acrylic,mixed fiber,yarn material etc to knit ready-made sweater,collar ,vamp
,hat,gloves,scarf and accessories of cloth. So as to achieve multi-functional all-in-one machine
Workshop assembly line after layer upon layer of strict testing to ensure the stable and efficient work of the machine

LCD Touch screen

Humanized design control interface large memory capacity, can store about 1000 patterns, for tens of thousands of lines of complex
patterns can also be read quickly without waiting. Stable performance make the operation more convenient, easy to learn
ndunderstand.

Positive feed yarn device

Positive yarn feed device could reduce resistance while yarn is moving , suit for fabrice with lace of elasticity and brittle
fabric to make the fabric even and improve knitting efficiency.

Motorized inversion bar & Tight handing head

The carriage inversion bar driven by motor ,carriage return is more accurate Tight is controlled by the motor ,to achieve
different degrees of tight tuck,ranging from 0 to 80 .

Ultra-small Carriage

Further optimize the size of the machine carriage ,reduce the carriage return distance and improve the efficiency .

16 yarn carriages

The 16 yarns can be used by any weaving system and can be switched at any position. According to different knitting speed the
control program can automatically adjust the position of the yarn nozzle.

Plus wide transmission belt

Specifical design double row synchronizing transmission belt let the machine with more stable running performance .

Mainly specification

Gauge :	3G,3.5G,5G,7G,8G,9G,10G,12G,14G,16G,3-5-7G multi-gauge
Knitting width :	52 inches (60, 72, 80 inches Customizable)
knitting function:	Jacquard,Transfer,Miss,Intarsia,Pointelle,Cable,Hide And Other Regular Pattern Knitting Fuctions.(Noted:Tuck can't be knitted with other knitting action in same line)
Knitting speed:	1.4m/Second(Max), 32 section adjustable
Knitting system:	Single carriage with Double System
Stitch density:	Controlled by 32 section electricity, density adjustment driven by stepping motor, range: 0-650
Needle Bed Racking:	AC Servo Motor drive, the maximum racking within 2 inches
Needle Selection System:	8 section electronic needle actuator
Yarn Feeder:	2 pcs Proactive Yarn Feeders
Stitch system:	2*8 yarn carriers are arranged on the left and right sides of the 4 double side guide rails.
Yarn Carriers:	Advanced encoder reading pin.8-stage selecting needle setup composed of special electromagnet is regarded as efficient full width jacquard needle selector.
Transmission system:	Belt drive, High precision AC servo motor control.
Data input:	Input and output patterns via USB, PC and Internet
Protection system:	Automatic stopping device if yarn broken, yarn knot, batching, striking, completion, overload, designated starting and stopping, program error
Safety device:	The whole machine cover to reduce noise and dust, the protecting cover is equipped with stopping sensor, emergency stopping and power off device
Network	Has network interface,enable remote-monitoring via network,and connecting with ERP system.
Power Supply:	Voltage: AC 220V, Frequency: 50HZ/60HZ, Power:1KW
Volume and weight	24509001800mm 700kgs
